TL720D MEMS Gyroscope Sensor with Azimuth Angle (±180°), RS232/RS485 Output, and 10grms Anti-Vibration for AGV and Industrial Control

  • 1
  • 2
  • 3

Model Number : TL720D

Place of Origin : Guangdong, China

Brand Name : RION

Packaging Details : Carton

Price : 60 USD/Pieces

Certification : CE, ISO

MOQ : 1

Payment Terms : T/T,Paypal

Supply Ability : 3000/month

Delivery Time : 7 days for samples

gyro sensor power supply : DC5V

Output signal : RS232/RS485/TTL

Mesuring range : Azimuth Angle (±180)

Current (mA) : 40(5V)

Anti-vibration : 10grms,10~1000Hz

Azimuth accuracy (°/min) : <0.2

Weight : 152g(matched standard cable)

Working Temp.(℃) : -40 ~ +80

Contact Now

TL720D 152G 3-Axis Angular Sensor with Azimuth MODBUS Attitude Algorithm
The TL720D is a newly developed small-volume dynamic attitude sensor based on the latest MEMS inertial measurement platform. Utilizing advanced dynamic attitude algorithms for gyroscope angular velocity processing, it simultaneously outputs the carrier's azimuth angle. The product integrates inertial navigation algorithms and employs attitude angle data fusion models to minimize gyro short-term drift issues.
Key Features
Azimuth angle output
Strong vibration resistance
Light weight design
Long life with strong stability
Cost-effective solution
All solid state construction
Compact & lightweight design
RS232/RS485 output optional
Applications
AGV truck navigation
Car navigation systems
3D virtual reality
Platform stability control
Automotive safety systems
Industrial control applications
TL720D MEMS Gyroscope Sensor with Azimuth Angle (±180°), RS232/RS485 Output, and 10grms Anti-Vibration for AGV and Industrial Control
Technical Specifications
Parameter Specification
Measure range Azimuth Angle (±180)°
Acquisition bandwidth >100Hz
Nonlinear 0.1% of FS
Accelerometer
Accelerometer range ±4g
Accelerometer resolution 0.001g
Accelerometer accuracy 5mg
Bias instability (allan) 0.05mg
Speed random walk coefficient (allan) 0.015m/s/sqrt(h)
Bias stability (10s average) 0.15mg
Gyro
Gyro Angular Velocity Range ±250°/s
Angle random walk coefficient (allan) 0.30°/sqrt(h)
Bias stability (10s smooth) 10°/h
Starting time AGV application: 5~6s
AGM application: 1.5s
Input Voltage 9~36VDC / 5VDC (Optional)
Current 30mA(12V)
Working Temperature -40℃ ~ +80℃
Storage Temperature -40℃ ~ +85℃
Vibration 5g~10g
Impact 200g pk, 2ms, ½sine
Working life 10 years
Output rate 5Hz~200Hz can set
Output signal RS232 or RS485
MTBF ≥98000 hours / times
Insulation resistance ≥100 Megohm
Impact resistance 100g@11ms / 3 Axial Direction (Half Sinusoid)
Anti-vibration 10grms / 10~1000Hz
Protection IP67
Weight ≤135g (including 1 meter standard cable)
TL720D MEMS Gyroscope Sensor with Azimuth Angle (±180°), RS232/RS485 Output, and 10grms Anti-Vibration for AGV and Industrial Control
TL720D MEMS Gyroscope Sensor with Azimuth Angle (±180°), RS232/RS485 Output, and 10grms Anti-Vibration for AGV and Industrial Control
